🐞Building a Web Crawler with Amazon Lambda

🌐 中文版：繁體中文

Preface

This post is from reproducing a customer issue. To solve the customer’s problem, I tried to install Selenium Chromedriver and BeautifulSoup, package them into a Lambda Layer, and build a Lambda based on that layer, but kept getting a “Chromedriver file not found” error. After pit after pit of troubleshooting, this savior suddenly appeared: https://stackoverflow.com/questions/69047401/selenium-docker-container-runs-on-ec2-but-not-on-aws-lambda. Based on this article and the corresponding GitHub https://github.com/rchauhan9/image-scraper-lambda-container/tree/master, it mainly builds the Lambda via a container image, but before doing so you first package the needed packages and environment into an image.

But since the company Mac can’t install Docker, I first spun up an EC2 for most of the work.

The examples and the knowledge needed to build this post all reference the AWS official docs.

The whole flow is roughly as follows.

I drew the flowchart with mermaid, referencing this blog and the official doc tutorial:
https://shannonhung.github.io/posts/first-blog.html#%E5%89%8D%E8%A8%80
https://mermaid.js.org/syntax/flowchart.html

    graph LR
   A(Create and configure EC2) --> B(Configure VPC)
   B(Configure VPC) --> C(Connect to EC2)
   C(Connect to EC2) --> D(Install Docker)
   D(Install Docker) --> E(Build image)
   E(Build image) -->  F(Test container)
   F(Test container) --> G(Push to repository)
   G(Push to repository) --> H(Build Lambda)

Installing EC2

Name: TestWebScrapping
AMI: Amazon Linux 2
Region: us-east-1
Access Key: "CWAccess.pem"

Configuring the network

IPv4 CIDR: 10.1.0.0/16

Subnet: TestSubnet1
CIDR: 10.1.0.0/24
RouteTable:
10.1.0.0/16   |  local
0.0.0.0/0     |  Internet Gateway

Security Group
TCP 443 Source: 0.0.0.0/0
TCP 80 Source: 0.0.0.0/0
TCP 22 Source: 0.0.0.0/0

After creation, connect to EC2

Imgur

1	ssh -i "CWAccess.pem" ec2-user@ec2-3-83-139-226.compute-1.amazonaws.com

Installing Docker

For the install docs here, refer to the AWS official guide:
https://docs.aws.amazon.com/zh_cn/AmazonECS/latest/developerguide/create-container-image.html

sudo yum update -y
sudo amazon-linux-extras install docker
sudo service docker start
sudo usermod -a -G docker ec2-user

# log back into the terminal at this point
docker info

Building the Docker image

First create a few files in the home directory:

requirements.txt
entry.sh
app/app.py

requirements.txt

requests==2.25.0
selenium==3.14.0
beautifulsoup4==4.9.3
Pillow==8.0.1
boto3
botocore

entry.sh

#!/bin/sh
if [ -z "${AWS_LAMBDA_RUNTIME_API}" ]; then
    exec /usr/bin/aws-lambda-rie /usr/local/bin/python -m awslambdaric $1
else
    exec /usr/local/bin/python -m awslambdaric $1
fi

Give it execute permission

1	sudo chmod +x entry.sh

app/app.py

1
2
3

mkdir app
cd app
vim app.py

import json

from selenium import webdriver
from selenium.webdriver.chrome.options import Options
from selenium.webdriver.support.ui import WebDriverWait
from selenium.webdriver.common.by import By
from selenium.webdriver.support import expected_conditions as EC

def handler(event, context):

    chrome_options = Options()

    chrome_options.add_argument('--autoplay-policy=user-gesture-required')
    chrome_options.add_argument('--disable-background-networking')
    chrome_options.add_argument('--disable-background-timer-throttling')
    chrome_options.add_argument('--disable-backgrounding-occluded-windows')
    chrome_options.add_argument('--disable-breakpad')
    chrome_options.add_argument('--disable-client-side-phishing-detection')
    chrome_options.add_argument('--disable-component-update')
    chrome_options.add_argument('--disable-default-apps')
    chrome_options.add_argument('--disable-dev-shm-usage')
    chrome_options.add_argument('--disable-domain-reliability')
    chrome_options.add_argument('--disable-extensions')
    chrome_options.add_argument('--disable-features=AudioServiceOutOfProcess')
    chrome_options.add_argument('--disable-hang-monitor')
    chrome_options.add_argument('--disable-ipc-flooding-protection')
    chrome_options.add_argument('--disable-notifications')
    chrome_options.add_argument('--disable-offer-store-unmasked-wallet-cards')
    chrome_options.add_argument('--disable-popup-blocking')
    chrome_options.add_argument('--disable-print-preview')
    chrome_options.add_argument('--disable-prompt-on-repost')
    chrome_options.add_argument('--disable-renderer-backgrounding')
    chrome_options.add_argument('--disable-setuid-sandbox')
    chrome_options.add_argument('--disable-speech-api')
    chrome_options.add_argument('--disable-sync')
    chrome_options.add_argument('--disk-cache-size=33554432')
    chrome_options.add_argument('--hide-scrollbars')
    chrome_options.add_argument('--ignore-gpu-blacklist')
    chrome_options.add_argument('--ignore-certificate-errors')
    chrome_options.add_argument('--metrics-recording-only')
    chrome_options.add_argument('--mute-audio')
    chrome_options.add_argument('--no-default-browser-check')
    chrome_options.add_argument('--no-first-run')
    chrome_options.add_argument('--no-pings')
    chrome_options.add_argument('--no-sandbox')
    chrome_options.add_argument('--no-zygote')
    chrome_options.add_argument('--password-store=basic')
    chrome_options.add_argument('--use-gl=swiftshader')
    chrome_options.add_argument('--use-mock-keychain')
    chrome_options.add_argument('--single-process')
    chrome_options.add_argument('--headless')

    chrome_options.add_argument('--user-data-dir={}'.format('/tmp/user-data'))
    chrome_options.add_argument('--data-path={}'.format('/tmp/data-path'))
    chrome_options.add_argument('--homedir={}'.format('/tmp'))
    chrome_options.add_argument('--disk-cache-dir={}'.format('/tmp/cache-dir'))

    driver = webdriver.Chrome(
        executable_path='/usr/bin/chromedriver',
        options=chrome_options)

    if driver:
        print("Selenium Driver Initiated")

    response = {
        "statusCode": 200,
        "body": json.dumps(html, ensure_ascii=False)
    }

    return response

1	vim Dockerfile

Dockerfile

# Define global args
ARG FUNCTION_DIR="/home/app/"
ARG RUNTIME_VERSION="3.9"
ARG DISTRO_VERSION="3.12"
# Stage 1
FROM python:${RUNTIME_VERSION}-alpine${DISTRO_VERSION} AS python-alpine

RUN apk add --no-cache \
    libstdc++
# Stage 2
FROM python-alpine AS build-image

RUN apk add --no-cache \
    build-base \
    libtool \
    autoconf \
    automake \
    libexecinfo-dev \
    make \
    cmake \
    libcurl

ARG FUNCTION_DIR
ARG RUNTIME_VERSION

RUN mkdir -p ${FUNCTION_DIR}

RUN python${RUNTIME_VERSION} -m pip install awslambdaric --target ${FUNCTION_DIR}

# Stage 3
FROM python-alpine as build-image2

ARG FUNCTION_DIR

WORKDIR ${FUNCTION_DIR}

COPY --from=build-image ${FUNCTION_DIR} ${FUNCTION_DIR}

RUN apk update \
    && apk add gcc python3-dev musl-dev \
    && apk add jpeg-dev zlib-dev libjpeg-turbo-dev

COPY requirements.txt .

RUN python${RUNTIME_VERSION} -m pip install -r requirements.txt --target ${FUNCTION_DIR}
# Stage 4
FROM python-alpine

ARG FUNCTION_DIR

WORKDIR ${FUNCTION_DIR}

COPY --from=build-image2 ${FUNCTION_DIR} ${FUNCTION_DIR}

RUN apk add jpeg-dev zlib-dev libjpeg-turbo-dev \
    && apk add chromium chromium-chromedriver

ADD https://github.com/aws/aws-lambda-runtime-interface-emulator/releases/latest/download/aws-lambda-rie /usr/bin/aws-lambda-rie

RUN chmod 755 /usr/bin/aws-lambda-rie

COPY app/* ${FUNCTION_DIR}
COPY entry.sh /

ENTRYPOINT [ "/entry.sh" ]

CMD [ "app.handler" ]

Build the image

1	docker build -t awsLambdacrawler .

Once built, check whether it succeeded with:

1	docker images

Testing the container

1	docker run -p 9000:8080 <IMAGE_ID>

The output will look like this
Imgur

Now open another terminal to invoke and test the request

1	curl -XPOST "http://localhost:9000/2015-03-31/functions/function/invocations" -d '{}'

Imgur

Then create an ECR Repository (on the local MacBook)

1	aws ecr create-repository --repository-name cx-lambda --image-scanning-configuration scanOnPush=true

1	docker tag awsLambdacrawler:latest <ENTER YOUR CONTAINER REPOSITORY URI>:latest

Then on the local MacBook, get the ECR password

1	aws ecr get-login-password

Copy the password

1	docker login <YOUR AWS ACCOUNT ID>.dkr.ecr.<YOUR REGION>.amazonaws.com (http://amazonaws.com/)>

username: AWS
password: the password just copied

Push the image to the repository

1	docker push <YOUR AWS ACCOUNT ID>.dkr.ecr.<YOUR REGION>.amazonaws.com (http://amazonaws.com/)

Check it in the ECR console
Imgur

Creating the Lambda

Go to Lambda Console > Create Function > Container Image

1 2	Function Name: ScrappingfromImage Container image URI: 125657041963.dkr.ecr.us-east-1.amazonaws.com/cx-lambda:latest

Configuring Lambda network access

If you want the Lambda function to connect to the external network, unlike EC2, you need to attach the Lambda to your own VPC, put the Lambda in a private subnet, and that private subnet’s route table must have its default route set to a NAT Gateway.
Because when Lambda connects to a VPC it creates an ENI, and that ENI by default only takes a private IP, so a NAT Gateway is needed to translate between public and private IPs, and it connects to the NAT Gateway via a feature called V2N.

If interested, refer to these two official docs, which detail Lambda’s networking mechanism:
https://docs.aws.amazon.com/zh_tw/lambda/latest/dg/foundation-networking.html
https://aws.amazon.com/tw/blogs/compute/announcing-improved-vpc-networking-for-aws-lambda-functions/

As a flowchart it looks like this:

    flowchart LR
    subgraph Custom VPC
        direction LR
        c1(Lambda) ---> a2(NATGateway)
        subgraph Public Subnet
            direction LR
            a2(NATGateway)
        end
        subgraph Private Subnet
            direction LR
            c1(Lambda)
        end
    end

Imgur
